12V Bataryalar İçin
TECHNICAL DATA
| Mains voltage |
1~ 230V |
| Mains Frequency |
50/60 Hz |
| AC input current in A effectiv |
2,3 A |
| Mains fuse |
16,0 A |
| Nominal Power |
315,0 W |
| Power Factor (pf) |
0,62 |
| Duty Cycle |
100,0 % |
| Nominal output voltage |
12,0 V |
| Output Voltage Range |
2-16,8V |
| Charging current / output current nominal |
20,0 A |
| Dimension / l |
245,0 mm |
| Dimension / h |
155,0 mm |
| Weight |
1,9 kg |
| Ambient Temperature Range |
-20°C / +40°C |
| Maximum Relative Humidity |
85,0 |
| Maximum Altitude above Sea level |
2000m |
| Protection class |
40,0 |
| Test symbol |
CE |
